[Android] Qr Zxing 라이브러리 적용하기

https://github.com/journeyapps/zxing-android-embedded

GitHub - journeyapps/zxing-android-embedded: Barcode scanner library for Android, based on the ZXing decoder



이 깃허브에 들어가게 되면

build.gradle에 추가하기!

implementation 'com.journeyapps:zxing-android-embedded:4.3.0'



Qr코드의 생성과 인식을 둘다 하기위해 페이지 구현

<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity">

    <Button
        android:id="@+id/btnCreate"
        android:layout_width="200dp"
        android:layout_height="wrap_content"
        android:text="QR 생성"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintLeft_toLeftOf="parent"
        app:layout_constraintRight_toRightOf="parent"
        app:layout_constraintTop_toTopOf="parent" />

    <Button
        android:layout_marginTop="10dp"
        android:id="@+id/btnScan"
        android:layout_width="200dp"
        android:layout_height="wrap_content"
        android:text="QR 인식"
        app:layout_constraintTop_toBottomOf="@+id/btnCreate"
        app:layout_constraintLeft_toLeftOf="parent"
        app:layout_constraintRight_toRightOf="parent" />

</androidx.constraintlayout.widget.ConstraintLayout>

class MainActivity : AppCompatActivity() {

    private lateinit var binding : ActivityMainBinding
    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        binding = ActivityMainBinding.inflate(layoutInflater)
        setContentView(binding.root)

        binding.btnCreate.setOnClickListener {
            val intent = Intent(this, CreateQRActivity::class.java)
            startActivity(intent)
        }

        binding.btnScan.setOnClickListener {
            val intent = Intent(this, ScanQRActivity::class.java)
            startActivity(intent)
        }
    }
}



처음 화면부터 만들어주고



다음은 Qr이미지 생성하러!!

Qr 인식 페이지

<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".CreateQRActivity">

    <ImageView
        android:id="@+id/imageViewQrCode"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        app:layout_constraintBottom_toTopOf="@+id/btn_album"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent" />

    <Button
        android:id="@+id/btn_album"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:text="사진 저장"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent" />

</androidx.constraintlayout.widget.ConstraintLayout>

class CreateQRActivity : AppCompatActivity() {

    private lateinit var binding : ActivityCreateqrBinding

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)

        binding = ActivityCreateqrBinding.inflate(layoutInflater)
        setContentView(binding.root)

        try {
            val barcodeEncode = BarcodeEncoder()
            // Qr 코드안에 담고싶은 내용을 담으면 됩
            val bitmap = barcodeEncode.encodeBitmap("Viva yun Tistory", BarcodeFormat.QR_CODE, 400, 400)
            val imageViewQrCode : ImageView = binding.imageViewQrCode
            imageViewQrCode.setImageBitmap(bitmap)
        } catch (e : Exception) {
            Toast.makeText(this, "네트워크 에러", Toast.LENGTH_SHORT).show()
        }
    }
}



이렇게 넣어주면



간단하게 이미지 생성페이지까지 완료



다음은 인식하러 가야죠

<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".ScanQRActivity">


    <Button
        android:id="@+id/btnScan"
        android:layout_width="200dp"
        android:layout_height="wrap_content"
        android:layout_marginTop="250dp"
        android:text="SCAN"
        app:layout_constraintLeft_toLeftOf="parent"
        app:layout_constraintRight_toRightOf="parent"
        app:layout_constraintTop_toTopOf="parent" />

    <Button
        android:id="@+id/btnCustomScan"
        android:layout_width="200dp"
        android:layout_height="wrap_content"
        android:layout_marginTop="10dp"
        android:text="Custom SCAN"
        app:layout_constraintLeft_toLeftOf="parent"
        app:layout_constraintRight_toRightOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/btnScan" />

    <TextView
        android:id="@+id/txtResult"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_margin="10dp"
        android:background="#eaeaea"
        android:padding="10dp"
        android:text="결과 텍스트"
        android:textAlignment="center"
        android:textColor="@color/black"
        android:textSize="15sp"
        app:layout_constraintTop_toBottomOf="@+id/btnCustomScan"/>

</androidx.constraintlayout.widget.ConstraintLayout>



기본 Qr인식 화면

결과 화면도 보기위해 text 추가

<merge xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools">

    <com.journeyapps.barcodescanner.BarcodeView
        android:id="@+id/zxing_barcode_surface"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        app:zxing_framing_rect_height="300dp"
        app:zxing_framing_rect_width="300dp"
        app:zxing_preview_scaling_strategy="fitCenter" />

    <com.journeyapps.barcodescanner.ViewfinderView
        android:id="@+id/zxing_viewfinder_view"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        app:zxing_possible_result_points="@color/zxing_custom_possible_result_points"
        app:zxing_result_view="@android:color/holo_orange_light"
        app:zxing_viewfinder_laser="@color/zxing_custom_viewfinder_laser"
        app:zxing_viewfinder_laser_visibility="true"
        app:zxing_viewfinder_mask="@color/zxing_custom_viewfinder_mask" />

    <!-- mask 영역에 적혀있는 스캔 안내 문구 영역 -->
    <TextView
        android:id="@+id/zxing_status_view"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_gravity="bottom|center_horizontal"
        android:background="@color/zxing_transparent"
        android:padding="10dp"
        android:text="@string/zxing_msg_default_status"
        android:textColor="@color/zxing_status_text" />

</merge>

class ScanQRActivity : AppCompatActivity() {

    private lateinit var binding : ActivityScanqrBinding

    private val barcodeLauncher = registerForActivityResult(ScanContract()) { result: ScanIntentResult ->
        if (result.contents == null) {
            Toast.makeText(this, "Cancelled", Toast.LENGTH_SHORT).show()
        } else {
            Toast.makeText(this, "Scanned : " + result.contents, Toast.LENGTH_SHORT).show()

            binding.txtResult.text = result.contents.toString()

        }
    }

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)

        binding = ActivityScanqrBinding.inflate(layoutInflater)
        setContentView(binding.root)

        binding.btnScan.setOnClickListener {
            onScanButtonClicked()
        }

        binding.btnCustomScan.setOnClickListener {
            onCustomScanButtonClicked()
        }

    }

    private fun onScanButtonClicked(){
        // 세로모드
        var options = ScanOptions()
        options.setOrientationLocked(false)
        barcodeLauncher.launch(ScanOptions())
    }

    private fun onCustomScanButtonClicked(){
        val options = ScanOptions()
        options.setOrientationLocked(false)
        options.setBeepEnabled(true)
        options.setPrompt("커스텀 QR 스캐너")
        options.captureActivity = CustomQrScannerActivity::class.java

        barcodeLauncher.launch(options)
    }
}

Flash를 추가한 커스텀 화면

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical">

    <com.journeyapps.barcodescanner.DecoratedBarcodeView
        android:id="@+id/decoratedBarcodeView"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        app:zxing_scanner_layout="@layout/custom_barcode_scanner" />

    <ImageView
        android:id="@+id/btnFlash"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginTop="10dp"
        android:layout_marginEnd="10dp"
        android:src="@drawable/ic_new_contest_active"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintTop_toTopOf="parent" />

</androidx.constraintlayout.widget.ConstraintLayout>

class CustomQrScannerActivity : AppCompatActivity() {

    private lateinit var binding : ActivityCustomQrScannerBinding
    private lateinit var captureManager : CaptureManager
    private lateinit var decoratedBarcodeView : DecoratedBarcodeView

    private var isFlash = false

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)

        binding = ActivityCustomQrScannerBinding.inflate(layoutInflater)
        setContentView(binding.root)

        decoratedBarcodeView = binding.decoratedBarcodeView

        captureManager = CaptureManager(this, decoratedBarcodeView)
        captureManager.initializeFromIntent(intent, savedInstanceState)
        captureManager.setShowMissingCameraPermissionDialog(true, "카메라 권한 요청")
        captureManager.decode()

        binding.btnFlash.setOnClickListener {
            if (!isFlash) {
                isFlash = true
                decoratedBarcodeView.setTorchOn()
            } else {
                isFlash = false
                decoratedBarcodeView.setTorchOff()
            }
        }
    }

    override fun onResume() {
        super.onResume()
        captureManager.onResume()
    }

    override fun onPause() {
        super.onPause()
        captureManager.onPause()
    }

    override fun onDestroy() {
        super.onDestroy()
        captureManager.onDestroy()
    }

    override fun onSaveInstanceState(outState: Bundle) {
        super.onSaveInstanceState(outState)
        captureManager.onSaveInstanceState(outState)
    }

    override fun onRequestPermissionsResult(
        requestCode: Int,
        permissions: Array<out String>,
        grantResults: IntArray
    ) {
        super.onRequestPermissionsResult(requestCode, permissions, grantResults)
        captureManager.onRequestPermissionsResult(requestCode, permissions, grantResults)
    }
}





결과 페이지 까지 완료
